24” Diameter Solid Covers
Standard covers are available in 1/4″ thickness and above rated at 300 Lbs pedestrian load rated. The steel covers in a 10GA material will not be rated. Steel covers are of a smooth surface available in a non-corrosive enamel finish, powder coating, epoxy coating, or galvanized finish. The fiberglass covers and the aluminum covers are complete with a diamond plate finish. The fiberglass covers have a UV inhibitor to protect against fading or chaulking. All covers provided by AK Industries carry a one-year warranty against defects in material and/or workmanship.
Note
- Round Covers: (6) 9/16″ holes on a 26 1/2″ Bolt Circle
- Square Covers: (8) 9/16″ holes on a 26 1/2″ Bolt Pattern
Documents
One Year Warranty (PDF)
Select a Variant
| Part Number | Description | Weight | Thickness | Technical Drawings |
|---|---|---|---|---|
GL-24FSC-32 | Solid fiberglass w/ lip O.D. 32” | 17lbs | Cover: 1/4”, Lip: 5/8” | |
LB-10-S2400 | Solid Steel | 24lbs | 10GA | |
Solid steel | N/A | 44lbs | 1/4" | |
LB-A2400.25 | Solid Aluminum | 24lbs | 1/4" | |
LB-S2400 PERF | Solid Perforated Steel | 42lbs | 1/4" | |
LB-A2400 PERF | Solid Perforated Aluminum | 22lbs | 1/4" |
